SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3121259
1.4 SPECIFICATIONS AND PERFORMANCE
DATA
Reach Specifications
Dimensional Data
Chassis
Table 1-6. Caterpillar 3024/C2.2
Fuel Diesel
No. of Cylinders 4
BHP 46.5 hp (34 kW)
Bore 3.307 in. (84 mm)
Stroke 3.9370 in. (112 mm)
Displacement 134.3 cu. in. (2.2L)
Oil Capacity 10 qt. (9.4 L)
Compression Ratio 19:1
Firing Order 1-3-4-2
Max. RPM 2800
Table 1-7. GM 3.0L
Fuel Gasoline or Gasoline/LP Gas
No. of Cylinders 4
BHP
Gasoline
LP
83 hp @ 3000 rpm
75 hp @ 3000 rpm
Bore 4.0 in. (101.6 mm)
Stroke 3.6 in. (91.44 mm)
Displacement 181 cu.in. (3.0 L, 2966 cc)
Oil Capacity w/filter 4.5 qts. (4.25 L)
Minimum Oil Pressure
at idle
Hot
6 psi (0.4 Bar) @ 1000 rpm
18 psi (1.2 Bar) @ 2000 rpm
Compression Ratio 9.2:1
Firing Order 1-3-4-2
Max. RPM 2800
Table 1-8. Perkins 404C-22
Fuel Diesel
No. of Cylinders 4
BHP 50 HP (37.3 kW)
Bore 3.3 in. (84 mm)
Stroke 3.9 in. (100 mm)
Firing Order 1-3-4-2
Displacement 135 cu.in. (2.2 L)
Oil Capacity w/filter 10 qt. (9.4 L)
Compression Ratio 23.3:1
Fuel Consumption 0.63 gal. (2.38 L) /hour
Table 1-9. Reach Specifications - 450
Max. Platform Height 45ft. (13.72 M)
Max. Horizontal Reach 24.5ft. (7.47 M)
Up & Over Height 25 ft. 2 in. (7.7 M)
Main Boom Up Angle 75°
Main Boom Down Angle -24°
Table 1-10. Dimensional Data - 450
Overall Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
6 ft. 6 in. (1.98 m)
6 ft. 10 in. (2.08 m)
6 ft. 11 in. (2.11 m)
Tailswing 0
Stowed Height 7 ft. 4.4 in. (2.25 m)
Stowed Length 21 ft. 4 in. (6.5 m)
Wheel base 78 in. (1.98 m)
Track Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
65.3 in. (1.66 m)
66.3 in. (1.69 m)
66.6 in. (1.69 m)
Ground Clearance 14 in. (0.36 m)
Table 1-11. Chassis Specifications - 450
Swing 357° non-continuous
Rated Gradeability
2WD
4WD
30%
45%
Max. Tire Load 7900 lb. (3583 kg)
Axle Oscillation 8 in. (0.2 m)
System Voltage 12 Volts
Max. Hydraulic System Operating
Pressure 4500 psi
(310 bar)
Gross Machine Weight
450A SII
450AJ SII
14,500 lbs. (6577 kg)
16,500 lbs. (7484 kg)
