ENVELOPE: Displayed if MODEL NUMBER = 7 or 8
LENGTH XXXX.X Current indicated boom length in inches.
ANGLE 1 XX.X Current indicated boom angle 1 in degrees.
ANGLE 2 XX.X Current indicated boom angle 2 in degrees.
A/D LNGTH XXXXX Current indicated boom length in A/D counts.
A/D ANG1 XXXXX Current indicated boom angle 1 in A/D counts or raw angle if
calibrated.
A/D ANG2 XXXXX Current indicated boom angle 2 in A/D counts or raw angel if
calibrated.
CAN STATISTICS: CAN Statistics as detected by Ground Module
RX/SEC XXX Number of received messages per second
TX/SEC XXX Number of transmitted messages per second
BUS OFF XX Number of bus off occurrences
PASSIVE XX Number of bus passive occurrences
Table 6-6. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2 nd
Line)
Description
