SECTION 6 - JLG CONTROL SYSTEM
3121623
– JLG Lift –
6-61
6 - TILT DRIVE CUT-OUT FUNCTION (CHK INC)
This menu allows to set ON or OFF the drive cut-out func-
tion.
The drive function is reduce or stopped above certain
incline
1. Press button 7 "SETUP“.
2. Press button 5 “PASSWORD”.
Using the remote control buttons to enter the pass-
word 6661.
NOTE: password above allow to choose the options shown on the
screen.
Once the correct password is accepted the display
shown “OK”.
3. Press button 9 “ESC”.
Repeat the above steps if “NO” appear on the dis-
play.
4. Press button 3 ”EXTRA”
5. Press button 1 "OPTIONAL".
6. Press button 6 "CHK INC"
7. Press button 1 ON to activate the function
8. Press button 2 OFF to deactivate the function
Press 5 times button 9 to Esc to escape
