SECTION 3 - CHASSIS & TURNTABLE
3-80 – JLG Lift – 3121623
MODEL WITH EXTERNAL FUEL FILTER
(no fuel filter in the tank)
– Empty the fuel tank by taking out screw „1“, (chapter
Checking the water trap) and allow the fuel to drain into a
clean vessel. This fuel can be reused later.
– Unscrew the fuel filter from its mount.
– Place a suitable vessel under the filter to trap the resid-
ual fuel.
– Pull off fuel supply line „1“at both ends of fuel filter „2“
and insert the new filter.
– Always renew the fuel filter. Note the arrows indicating
the correct direction of flow.
– Secure the filter to its mount.
– Fill the fuel tank with diesel oil. Air is vented from the fuel
system automatically.
– Check the fuel filter and lines for leaks after a short test
run.
AIR CLEANER MAINTENANCE
The filter cartridge should only be cleaned when the main-
tenance lamp lights at maximum speed.However, the filter
cartridge should always be re-placed after 500 operating
hours at the latest.
– Remove the air cleaner cover.
2443 / 12
2442 / 3
