SECTION 1 - SPECIFICATIONS
3121623 – JLG Lift – 1-5
HATZ ENGINE 1B40
PERKINS ENGINE 402D
Table 1-7. SPECIFICATIONS HATZ ENGINE 1B40
Type 1B40
Design Air-cooled four-stroke diesel engine
Combustion system Direct injection
Number of cylinders 1
Bore / stroke 88 / 76 mm
Displacement
462 cm 3
Lubricating oil capacity without oil sump with oil
sump
1.5 1) l, approx.
3.2 1) l, approx.
Difference between “max” and “min” levels without
oil sump with oil sump
0.8 1) l, approx.
2.2 1) l, approx.
Lubricating oil consumption (after running in) 1% of fuel consumption at full load max.)
Lubricating oil pressure (oil temperature 100 °C) 2.5 bars at 3000 r.p.m. (approx.)
Direction of rotation, power take-off end anti-clockwise
Valve clearance 10 - 30 °C
Inlet and exhaust valve 0.10 mm
or automatically 2)
Max. tilt angle in operation, in direction
Flywheel 25° down 3) all other directions 35° 3)
Weight (incl. fuel tank, air-cleaner, exhaust silencer,
recoil starter and electric starter) 55 kg approx.
Battery capacity max. 12 V / 60 Amp/h
Table 1-8. SPECIFICATIONS PERKINS ENGINE 402D
Type
402D-05 Engine
Maximum Operating Speed (rpm)
3600 rpm
Cylinders and Arrangement
In-Line two cylinder
Bore 67 mm (2.64 inch)
Stroke 72 mm (2.83 inch)
Displacement 0.507 L (30.939 in3)
Aspiration
NA (1)
Compression Ratio 23.5:1
Firing Order 1-2
Rotation that is viewed from the flywheel
Counterclockwise
Valve Lash Setting (Inlet) 0.20 mm (0.008 inch)
Valve Lash Setting (Exhaust)
0.20 mm (0.008 inch)
Injection Indirect
