More details about the BMS connectors are showed in the
wiring diagrams.
Resume of all BMS functions:
1. Check the voltage of every cell
2. Check the current absorption of the battery pack
3. Check the battery pack temperatures
4. Check the internal resistance of every cell
5. Balance the cell during the charge
6. Manage the cooling system in case of high tempera-
ture
7. Manage the charge
8. Manage the system in case of failure
9. Protect the cells from: overcharge, overdischarge,
overtempearture, overvoltgage, undervoltage
Table 3-14.
J1 Can Bus Module Socket
J2 Current Sensor Socket (LEM)
J3 Power and contactor socket
J4 Temperature sensor socket
J5 Voltage cells Measurements Socket – Resis-
tance to discharge the cells during the bal-
ancing step
