SECTION 6 - JLG CONTROL SYSTEM
6-28
– JLG Lift –
3121623
Table 6-4. Menu Input
X17JP - X20JP - X500AJ - X600AJ
ST1 GND A
ON
Outrigger N° 1 on the ground – the switch is released and A line is closed
OFF
Outrigger N° 1 lifted – the switch is pressed and A line is opened
ST1 GND B
ON
Outrigger N° 1 on the ground – the switch is released and B line is closed
OFF
Outrigger N° 1 lifted – the switch is pressed and B line is opened
ST1 OPEN A
ON
Do not consider
OFF
Do not consider
ST1 OPEN B
ON
Do not consider
OFF
Do not consider
ST2 GND A
ON
Outrigger N° 2 on the ground – the switch is released and A line is closed
OFF
Outrigger N° 2 lifted – the switch is pressed and A line is opened
ST2 GND B
ON
Outrigger N° 2 on the ground – the switch is released and B line is closed
OFF
Outrigger N° 2 lifted – the switch is pressed and B line is opened
ST2 OPEN A
ON
Do not consider
OFF
Do not consider
ST2 OPEN B
ON
Do not consider
OFF
Do not consider
ST3 GND A
ON
Outrigger N° 3 on the ground – the switch is released and A line is closed
OFF
Outrigger N° 3 lifted – the switch is pressed and A line is opened
ST3 GND B
ON
Outrigger N° 3 on the ground – the switch is released and B line is closed
OFF
Outrigger N° 3 lifted – the switch is pressed and B line is opened
ST3 OPEN A
ON
Do not consider
OFF
Do not consider
ST3 OPEN B
ON
Do not consider
OFF
Do not consider
ST4 GND A
ON
Outrigger N° 4 on the ground – the switch is released and A line is closed
OFF
Outrigger N° 4 lifted – the switch is pressed and A line is opened
ST4 GND B
ON
Outrigger N° 4 on the ground – the switch is released and B line is closed
OFF
Outrigger N° 4 lifted – the switch is pressed and B line is opened
ST4 OPEN A
ON
Do not consider
OFF
Do not consider
