SECTION 6 - JLG CONTROL SYSTEM
3121623 – JLG Lift – 6-47
FUNCTIONS SPEED RANGE
FUNCTION JOYSTICK
N°
TIME Sec
X17JP
X500AJ
TIME Sec
X20JP
X600AJ
TELESCOPE EXTEND J4 15" - 20" 21" - 28"
ENGINE RPM 3000 3600
TELESCOPE RETRACT J4 16" - 22" 16" - 20"
ENGINE RPM 3600 3600
TOWER BOOM UP J2 21" - 24" 30" - 35"
ENGINE RPM 3600 3600
TOWER BOOM DOWN J2 19" - 22" 30" - 35"
ENGINE RPM 2200 2200
UPPER BOOM UP J3 25" - 29" 35" - 40"
ENGINE RPM 2200 2200
UPPER BOOM DOWN J3 24" - 30" 35" - 40"
ENGINE RPM 2200 2200
BASKET ROTATE RIGTH J5 7" - 10" 7" - 10"
BASKET ROTATE LEFT J5 7" - 10" 7" - 10"
ENGINE RPM 1500 1500
SWING LEFT J7 40" - 45" 45" - 50"
SWING RIGTH J7 40" - 45" 45" - 50"
ENGINE RPM 1500 1500
JIB UP J6 7" - 10" 7" - 10"
JIB DOWN J6 7" - 10" 7" - 10"
ENGINE RPM 2200 2200
BASKET LEVEL UP J9 40" - 58" 33" - 55"
BASKET LEVEL DOWN J9 35" - 52" 37" - 50"
ENGINE RPM 1500 1500
Table 6-9. Time range (sec)
