SECTION 1 - SPECIFICATIONS
3121623 – JLG Lift – 1-3
1.3 POWER SOURCE
NOTE: RPM Tolerances are ± 50.
Table 1-4. Ground bearing pressure
PRESSURES AND REACTIONS TO THE GROUND
MODEL
ON TRACKS ON OUTRIGGER
Maximum ground bearing
pressure
[daN/cm²] - [PSI]
Maximum ground
bearing pressure
on each pad
[daN] - [lbf]
Maximum ground bearing
pressure
[daN/cm²] - [PSI]
X17JP-X500AJ 0,67 daN/cm² 9,7 PSI 1731 daN 3892 lbf 2,45 daN/cm² 35.5 PSI
X20JP-X600AJ 0,64 daN/cm² 9,2 PSI 2150 daN 4833 lbf 3,04 daN/cm² 45 PSI
Table 1-5. Power configuration
X17JP X20JP
Gasoline Engine Honda iGX440
15 hp (11.1 kW)
Diesel Engine Hatz 1B40
10 hp (7.46 kW)
Perkins 402.05
14 hp (10.44 Kw)
Electric Motor 90Ah 48V Lithium-Ion 90Ah 70V Lithium-Ion
AC Electric Motor 110V 50 Hz (2,2 KW)
120V 60 Hz (1.2 kW)
230V 50 Hz (2.2 kW)
230V 60 Hz (2.2 kW)
