SECTION 2 - BOOM
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
91
FIGURE 2-25. MANITOU HYDRAULIC QUICK ATTACH
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001144652
Ref
MANITOU HYDRAULILC QUICK ATTACH INSTALLATION, (if
equipped), (not available to order, see items 1 thru 17 for service)
A
1
0711234
1
HEX HD CAPSCREW, M12X170, GR10.9, (torque to 115 Nm/85
lb-ft)
2
0761007
1
HEX HD CAPSCREW, M10X14, GR8.8, (torque to 55 Nm/41 lb-ft)
3
2160016
3
GREASE FITTING
4
3291201
1
HEX NUT, M12X1.75
5
4812100
1
WASHER, 12mm
6
1001002523
1
PIN
7
Ref
AUXILIARY BOOM HYDRAULIC COMPONENTS, (See
HYDRAULIC CIRCUITS SECTION for Breakdown)
8
1001008948
1
WASHER
11
0100011
AR
LOCTITE 242
12
1001097141
1
PIN
13
1001098457
AR
LITHIUM GREASE
14
1001144651
2
HOSE ASSEMBLY
15
1001102941
1
QUICK ATTACH ASSEMBLY, (includes items 101 thru 116)
A
16
1001098146
AR
SHIM, 72X110X0.5mm
17
1001098147
AR
SHIM, 72X110X1.0mm
101
1001103375
1
WELDMENT
102
1001103522
1
CYLINDER
102
70023273
1
SEAL KIT
103
1001103523
2
PIN
104
1001103524
2
BOLT
105
1001103525
2
LOCKNUT
106
1001103526
2
CLAMP
107
1001103527
4
BOLT
108
1001103528
4
WASHER
109
1001103529
2
STRAIGHT FITTING
110
1001103530
1
HYDRAULIC BOLT
111
1001103531
5
O-RING
112
1001103532
1
HOSE ASSEMBLY
113
1001103533
1
CLAMP ASSEMBLY
114
1001103534
1
BANJO LINK
115
1001103536
1
HOSE ASSEMBLY
116
1001103537
1
HOSE ASSEMBLY
