Page 207
SECTION 5 - DRIVE TRAIN
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
205
FIGURE 5-20. REAR AXLE - FINAL REDUCTION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
91474037
2
PLUG
2
8035235
4
BOLT, M8X20
3
70020977
2
PLANETARY CARRIER ASSY, (3706PS, 3707PS, 33.7, 37.6 &
37.7)
3
70021001
2
PLANETARY CARRIER ASSY, (4014PS & 4017PS)
4
7028509
8
THRUST WASHER, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
4
7028509
6
THRUST WASHER, (4014PS)
5
91474163
200
NEEDLE BEARING, (44.8 per gear), (3706PS, 3707PS, 33.7, 37.6
& 37.7)
5
91474163
160
NEEDLE BEARING, (33.6 per gear), (4014PS)
5
91364093
160
NEEDLE BEARING, (37.2 per gear), (4017PS)
6
7028508
8
SNAP RING, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
6
7028508
6
SNAP RING, (4014PS)
7
7028510
8
GEAR, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
7
7028510
6
GEAR, (4014PS)
7
91364094
6
GEAR, (4017PS)
104
91364095
6
WASHER, (4017PS)
106
91364096
6
LOCKING THRUST WASHER, (4017PS)
108
70021030
6
THRUST WASHER, (4017PS)
109
91474162
6
BOLT, M10X50, (4017PS)
