SECTION 2 - BOOM
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 77
FIGURE 2-18. MANUAL QUICK ATTACH
ITEM PART NUMBER QTY DESCRIPTION REV
1001136181 Ref MANUAL QUICK ATTACH, (4014PS, if equipped), (not available to
order, see items 2 thru 21 for service) D
1001137542 Ref MANUAL QUICK ATTACH, (4017PS, if equipped), (not available to
order, see items 2 thru 21 for service) E
2 0701234 1 HEX HD CAPSCREW, M12X170, GR8.8, (torque to 97 Nm/42 lb-
ft)
3 0760605 1 HEX HD CAPSCREW, M6X10, GR8.8, (torque to 12 Nm/9 lb-ft)
4 0761007 1 HEX HD CAPSCREW, M10X14, GR8.8, (torque to 97 Nm/42 lb-ft)
5 1001161673 1 CHAIN
6 2160016 3 GREASE FITTING
7 3291201 2 HEX NUT, M12X1.75
9 4811900 6 WASHER, 8mm
10 4812100 2 WASHER, 12mm
11 8002027 1 ROD
12 1001008948 1 WASHER
13 0760808 6 HEX HD CAPSCREW, M8X16, GR8.8, (torque to 28 Nm/21 lb-ft)
14 1001136183 1 WELDMENT, (4014PS)
14 1001137544 1 WELDMENT, (4017PS)
15 1001156994 1 COVER, (4014PS)
15 1001161673 1 COVER, (4017PS)
16 1001136211 1 PIN, (4014PS)
16 1001137555 1 PIN, (4017PS)
17 1001136214 1 PIN
18 1001098457 AR LITHIUM GREASE
19 1001095650 AR LOCTITE 243
20 1001098146 AR SHIM, 72X110X0.5mm
21 1001098147 AR SHIM, 72X110X1.0mm
