SECTION 1 - FRAME AND ATTACHING PARTS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 19
ITEM PART NUMBER QTY DESCRIPTION REV
204 1001132860 1 SIDE HOOD GRILLE
205 1001132862 AR BONDING AGENT
1001145748 1 CHASSIS COVER PLATE, (4014PS), (not available to order, see
item 301 thru 318 for service) B
1001145749 1 CHASSIS COVER PLATE, (4017PS), (not available to order, see
item 301 thru 319 for service) B
1001145747 1 CHASSIS COVER PLATE, (3707PS, 37.7 & 33.7), (not available to
order, see item 303, 306, 313, 316 thru 318 & 320 thru 322 for
service) B
1001145746 1 CHASSIS COVER PLATE, (3706PS & 37.6), (not available to order,
see item 303, 306, 313, 316 thru 318 & 320 thru 322 for service) B
301 0630576 4 SCREW, M6X20
303 0761010 6 HEX HD CAPSCREW, M8X20, (4014PS & 4017PS)
303 0761010 8 HEX HD CAPSCREW, M8X20, (3706PS, 3707PS, 37.7 & 33.7,
37.6)
304 3290605 8 HEX LOCKNUT, M6X1
306 4812000 6 WASHER, 10mm, (4014PS & 4017PS)
306 4812000 8 WASHER, 10mm, (3706PS, 3707PS, 37.7, 33.7, & 37.6)
307 5211702 24 RIPP WASHER, 6mm
307 4811700 8 WASHER, 6mm
308 8006105 2 HINGE JOINT
309 8006242 4 SCREW, M6X40
310 1001005387 1 COVER
311 1001151057 1 LATCH ASSY
312 1001063175 1 PAWL
313 1001095650 AR LOCTITE 243
316 1001093031BL 1 REAR HYDRAULICS PANEL, (4014PS & 4017PS)
316 1001095974BL 1 PLATE COVER, (3706PS, 3707PS, 37.7, 33.7, & 37.6)
317 1001093143BL 1 COVER PLATE, (4014PS & 4017PS)
317 1001093007BL 1 COVER PLATE, (3707PS & 37.7)
317 1001093001BL 1 COVER PLATE, (3706PS & 37.6)
318 1001097499BL 1 COVER PLATE, (4014PS & 4017PS)
318 1001093029BL 1 HYDRAULICS PANEL, (3706PS, 3707PS, 37.7, 33.7, & 37.6)
319 1001118426 2 SPACER PLATE, (4017PS)
320 0760812 2 HEX HD CAPSCREW, M8X25, GR8.8, (3706PS, 3707PS, 37.6,
37.7, & 33.7)
321 4811902 2 WASHER, 8mm, (3706PS, 3707PS, 37.7, 33.7, & 37.6)
322 1001141765 1 COVER, (3706PS, 3707PS, 37.7, 33.7, & 37.6)
