SECTION 8 - HYDRAULIC CIRCUITS
372
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
31200722
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
410
1001144856
1
HOSE
411
1001144857
1
HOSE
412
Ref
HYDRAULIC TANK, (See HYDRAULIC COMPONENTS SECTION
for Breakdown)
503
3290801
3
HEX NUT, M8X1.25
504
4811902
3
WASHER, 8mm, (if equipped for ULS)
504
4811902
1
WASHER, 8mm, (if equipped for LS)
507
1001008720
1
CLIP
508
1001095650
AR
LOCTITE 243
509
1001100319
2
CLIP
511
1001145272
1
HOSE
512
1001145273
1
HOSE
520
1062255
1
TIE STRAP
521
4811900
2
WASHER, 8mm, (if equipped for LS)
531
1001135584
2
CONDUIT
536
5220800
3
HEX NUT, M8X1.25, (torque to 28 Nm/20.65 lb-ft)
602
2131010
1
ADAPTER, 90, (includes o-ring), (torque to 36-44 Nm/26.5-32.4 lb-
ft)
608
1001099269
2
ADAPTER, 45, (barb), (torque to 36-44 Nm/26.5-32.4 lb-ft)
735
1001008609
2
CLAMP, (torque to 5-6 Nm/3.6-4.4 lb-ft)
