SECTION 10 - ELECTRICAL
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
519
FIGURE 10-11. CAB ROOF HARNESS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001114334
1
CAB ROOF HARNESS, (includes all items)
B
1
4460434
1
CONNECTOR
1
4460268
14
TERMINAL
1
N.S.S.
1
PLUG
2
4460265
1
CONNECTOR
2
4460268
8
TERMINAL
2
N.S.S.
1
PLUG
3
1001116982
2
CONNECTOR
3
1001118379
1
TERMINAL
4
4461115
3
CONNECTOR
4
1001103564
3
WEDGE LOCK
4
4460746
2
TERMINAL
4
4460458
2
SEAL
5
4460994
1
CONNECTOR
5
1001118379
1
TERMINAL
6
4460260
1
CONNECTOR
6
1001118379
1
TERMINAL
7
1001116986
2
CONNECTOR
7
1001118385
4
TERMINAL
8
1001116984
1
CONNECTOR
8
1001118386
4
TERMINAL
8
N.S.S.
4
PLUG
9
1001116985
1
CONNECTOR
9
1001118386
3
TERMINAL
9
N.S.S.
5
PLUG
