SECTION 3 - ATTACHMENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
125
FIGURE 3-12. MULTI-PURPOSE BUCKETS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001128891
1
0.52m³ MULTI-PURPOSE BUCKET, (CE)
B
0930003
1
1.0m³ MULTI-PURPOSE BUCKET, (CE and AUS), (includes items
1 thru 23)
C
1
7028990
2
TILT CYLINDER
1
7028910
AR
CYLINDER SEAL KIT
2
7028911
2
PIN
3
7028912
6
NUT, (not shown)
4
7028913
2
PIN
5
7028914
2
PROTECTIVE PLATE
6
7028915
2
PIN
7
7028916
4
HEX HD SCREW
8
7028131
6
BUSHING
9
7028917
4
WASHER
10
7028918
6
GREASE NIPPLE
11
7028920
2
SCREW
12
7028919
4
SCREW
14
N.S.S.
1
WELDMENT
15
7028923
1
GAUGE
16
Ref
FEMALE SCREW COUPLER, (no longer available, order
1001097287 kit)
16
1001094555
1
FEMALE QUICK DISCONNECT COUPLING
17
Ref
MALE SCREW COUPLER, (no longer available, order
1001097287 kit)
17
1001094556
1
MALE QUICK DISCONNECT COUPLING
18
Ref
WELDMENT
19
7028982
1
HOSE ASSY
20
7028983
1
HOSE ASSY
21
7028984
2
HOSE ASSY
22
7028985
1
HOSE ASSY
23
7028991
1
HOSE ASSY
K1
1001097287
1
QUICK DISCONNECT COUPLING KIT, (includes items 16, 17, dust
cap and dust plug)
