SECTION 10 - ELECTRICAL
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
535
FIGURE 10-19. RIDE AND FLOAT CONTROLLER HARNESS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001143047
1
RIDE AND FLOAT CONTROLLER HARNESS, (includes all items)
A
1
1001116808
1
PLUG CONNECTOR, (includes rear seal
1
4460909
1
HOUSING
1
4460915
1
WEDGE LOCK
1
4460928
7
TERMINAL
1
4460518
5
PLUG
2
4460884
1
PLUG CONNECTOR, (includes rear seal)
2
80604021
1
WEDGE LOCK
2
4460465
4
TERMINAL
3
1001116978
1
CONNECTOR PLUG
3
1001118381
34
TERMINAL
3
1001118391
3
PLUG
4
1001116774
1
CONNECTOR PLUG, (includes rear seal)
4
4460908
1
HOUSING
4
4460915
1
WEDGE LOCK
4
4460518
8
PLUG
4
4460918
2
TERMINAL
4
4460928
2
TERMINAL
5
1001116976
1
CONNECTOR
5
1001118380
34
TERMINAL
5
1001118391
3
PLUG
6
4460931
1
CONNECTOR, (includes rear seal)
6
80604024
1
WEDGE LOCK
6
4460464
6
TERMINAL
6
4460466
2
PLUG
