SECTION 3 - ATTACHMENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
99
FIGURE 3-2. SIDE SHIFT CARRIAGE ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1170002
1
SIDE SHIFT CARRIAGE ASSY, (CE), (Lamy), (includes items 1 thru
5 & 7 thru 13)
G
1
N.S.S.
1
WELDMENT
2
7028136
1
FORK CARRIER BAR
3
7028137
2
COLLAR
4
3291005
2
NUT
5
0701029
2
CAPSCREW
6
Ref
FORK TINE, (See FORK TINES for Breakdown)
7
70021558
1
CYLINDER
8
70021559
2
BOLT
9
70021560
1
PIN
10
70021561
1
PIN
11
70021562
2
WASHER
12
70021563
2
ROLL PIN
13
N.S.S.
1
SN PLATE
4
3291005
2
NUT
