SECTION 3 - ATTACHMENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
127
FIGURE 3-13. MANURE BUCKET
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0930004
1
1.0m³ MANURE BUCKET, (CE and AUS), (includes all items)
D
1
N.S.S.
1
BUCKET ASSY
2
7028133
1
SIDE PLATE ASSY
3
7028132
1
BLADE ASSY, (includes blade and the following hardware)
3
7029356
8
HEX LOCKNUT, M16-8
3
70023484
8
BOLT, M16X60, GR10.9
4
7028126
2
ADJUSTING BRACKET
5
7028125
1
GRAPPLE
6
7028127
2
TILT CYLINDER
6
7028910
AR
CYLINDER SEAL KIT
7
7028131
6
BUSHING
8
7028128
2
PIN
9
7028129
2
LOCKING PIN
10
7028130
2
PIN
11
7028135
4
ROLL PIN
12
7028134
8
ROLL PIN
13
7028124
2
CIRCLIP
14
7029749
1
CONNECTING ASSY
15
7028986
1
HOSE ASSY
16
7028987
1
HOSE ASSY
17
7028988
1
HOSE ASSY
18
7028989
1
HOSE ASSY
19
7028984
2
HOSE ASSY
20
Ref
FEMALE SCREW COUPLER, (no longer available, order
1001097287 kit)
20
1001094555
1
FEMALE QUICK DISCONNECT COUPLING
21
Ref
MALE SCREW COUPLER, (no longer available, order
1001097287 kit)
21
1001094556
1
MALE QUICK DISCONNECT COUPLING
K1
1001097287
1
QUICK DISCONNECT COUPLING KIT, (includes items 20, 21, dust
cap and dust plug)
