SECTION 8 - HYDRAULIC CIRCUITS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 391
FIGURE 8-13. EXTEND/RETRACT CYLINDER CIRCUIT
ITEM PART NUMBER QTY DESCRIPTION REV
2 0700612 4 HEX HD CAPSCREW, M6X25, GR8.8, (torque to 11 Nm/8.11 lb-ft)
3 0700614 1 HEX HD CAPSCREW, M6X30, GR8.8, (torque to 11 Nm/8.11 lb-ft)
4 0700617 8 HEX HD CAPSCREW, M6X45, GR8.8, (torque to 11 Nm/8.11 lb-ft)
5 2110808 2 ADAPTER, STRAIGHT, (includes o-ring)
10 3900362 6 BUTTON HD CAPSCREW, M6-1X12mm
11 4811700 10 WASHER, 6mm
17 1001144559 1 TWIN HOSE
19 1001008805 2 SEAL
20 1001009124 9 HARD WASHER
22 1001092129 1 CLAMP WITH COVER
24 1001093387 8 CLAMP
32 1001103554 4 CLAMP COVER PLATE
33 1001104032 1 PIPE
34 1001104033 1 PIPE
35 1001104670 1 HOSE GUIDE BRACKET
36 1001104717 1 IGUS CHAIN GUIDE BRACKET
38 1001115210 1 CHAIN GUIDE PLATE
42 Ref EXTEND/RETRACT CYLINDER, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
101 0700618 4 HEX HD CAPSCREW, M6X50, GR8.8, (torque to 12 Nm/8.85 lb-ft)
102 0700817 4 HEX HD CAPSCREW, M8X45, GR8.8, (torque to 28 Nm/20.65 lb-ft)
112 2110812 2 ADAPTER, STRAIGHT, (includes o-ring)
125 4811700 4 WASHER, 6m
126 4811900 4 WASHER, 8mm
146 1001144869 1 HOSE ASSY
147 1001144870 1 HOSE ASSY
152 1001095650 AR LOCTITE 243
156 1001098123 4 TRIPLE CLAMP COVER PLATE
157 1001098128 4 TRIPLE CLAMP
164 Ref MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
