SECTION 9 - HYDRAULIC COMPONENTS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 431
FIGURE 9-5. EXTEND/RETRACT CYLINDER AND HARDWARE
ITEM PART NUMBER QTY DESCRIPTION REV
1001129530 1 EXTEND/RETRACT CYLINDER, (4014PS), (includes items 1 thru
19) A
1 70024435 1 CASE ASSY
2 70020521 1 PISTON ROD ASSY
3 70020522 1 GLAND ASSY, (includes item 5), (apply Delo #5249 and torque to
320-370 Nm/236.01-272.89 lb-ft)
4 70020523 1 PISTON, (torque to 815-865 Nm/601.11-637.99 lb-ft)
5 Kit K1 1 BEARING, (high strength / high temperature retaining compound)
6 Kit K1 1 WIPER
7 Kit K1 1 ROD SEAL
8 Kit K1 1 O-RING
9 Kit K1 1 BACKRING
10 Kit K1 1 O-RING
11 Kit K1 1 PISTON SEAL
12 Kit K1 2 PISTON GUIDE RING
13 Kit K1 2 O-RING
14 70020524 1 SPACER
15 Kit K1 1 SET SCREW, M10X16, (apply high strength / high temperature
retaining compound and torque to 20-25 Nm/14.75-18.43 lb-ft)
16 7029623 2 BUFFER DISC
17 1001002815 1 LOAD CONTROL VALVE
18 7029626 4 COUNTERSUNK SCREW, (apply high strength / high temperature
retaining compound and torque to 20-25 Nm/14.75-18.43 lb-ft)
19 70020516 4 HEX SOCKET HEAD SCREW, M8X45
101 314689 4 RETAINING RING
108 3020040 AR MOLY PASTE LUBRICANT
113 8307904 AR SHIM, 2.0X0.048X3.0
114 8310093 AR SHIM, 2.0X0.075X3.50
115 1001002489 1 PIN
116 1001002498 1 PIN
123 1001092297 2 SPACER TUBE
K1 70020525 1 SEAL KIT, (includes items 5 thru 13 & item 15)
