SECTION 8 - HYDRAULIC CIRCUITS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 395
FIGURE 8-15. TILT AND TILT COMPENSATION CYLINDER CIRCUIT
ITEM PART NUMBER QTY DESCRIPTION REV
2 0700615 2 HEX HD CAPSCREW, 6X40mm, GR8.8, (torque to 11Nm/8 lb-ft)
8 4811700 3 HARD WASHER, (3706PS & 37.6)
8 4811700 4 FLAT WASHER, 6mm, (3707PS, 33.7 & 37.7)
15 1001144553 1 TWIN HOSE ASSY, (3706PS & 37.6)
15 1001144555 1 TWIN HOSE ASSY, (3707PS, 33.7 & 37.7)
16 1001101002 1 TUBE ASSY, (3706PS & 37.6)
16 1001002787 1 TUBE ASSY, (3707PS, 33.7 & 37.7)
17 1001101003 1 TUBE ASSY, (3706PS & 37.6)
17 1001002788 1 TUBE ASSY, (3707PS, 33.7 & 37.7)
20 1001002816 2 CLAMP
21 1001003435 2 ADAPTER, (includes o-ring)
23 1001092129 1 CLAMP SET, (3706PS & 37.6)
23 1001092129 2 CLAMP SET, (3707PS, 33.7 & 37.7)
25 1001095650 AR LOCTITE 243
28 0700618 2 HEX HD CAPSCREW, M6X50, GR8.8
101 0700825 2 HEX HD CAPSCREW, M8X85, GR8.8, (torque to 28 Nm/20.65 lb-ft)
103 0760807 1 HEX HD CAPSCREW, 8X14 MM, GR8.8, (torque to 23 Nm/17 lb-ft)
105 1062255 5 TIE WRAP, (3706PS & 37.6)
105 1062255 6 TIE WRAP, (3707PS, 33.7 & 37.7)
107 2110608 1 ADAPTER, (includes o-ring)
108 2110812 2 CONNECTOR, (includes o-ring)
110 2130606 1 ELBOW, 90, (includes o-ring)
111 2130608 3 ADAPTER, 90, (includes o-ring)
121 3290801 2 HEX NUT, M8X1/25
122 4811900 5 FLAT WASHER, 8mm
125 10719267 2 CLAMP, (torque to 4.5-5 Nm/3.31-3.68 lb-ft)
128 Ref TILT COMPENSATION CYLINDER, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
129 1001144821 1 HOSE ASSY, (3706PS & 37.6)
129 1001144832 1 HOSE ASSY, (3707PS, 33.7 & 37.7)
130 1001144821 1 HOSE ASSY, (3706PS & 37.6)
130 1001144833 1 HOSE ASSY, (3707PS, 33.7 & 37.7)
132 1001002817 1 CLAMP PLATE
133 1001002818 1 CLAMP HALF
137 1001008805 2 SEAL
148 Ref MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
149 1001108529 1 ANTI-KICK BACK VALVE
151 1001144828 1 HOSE ASSY
152 1001144829 1 HOSE ASSY
153 1001144822 1 HOSE ASSY, (3706PS & 37.6)
153 1001144830 1 HOSE ASSY, (3707PS, 33.7 & 37.7)
154 1001144823 1 HOSE ASSY, (3706PS & 37.6)
154 1001144831 1 HOSE ASSY, (3707PS, 33.7 & 37.7)
155 1001112726 1 BRACKET
156 1001151080 2 SPLIT POLY CONDUIT
202 2110808 2 CONNECTOR, (includes o-ring)
204 2172108 2 ELBOW, 90, (includes o-ring)
213 Ref TILT CYLINDER, (See HYDRAULIC COMPONENTS SECTION for
Breakdown)
