SECTION 3 - ATTACHMENTS
106
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
31200722
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
139
3291005
4
HEX LOCKNUT, M10X1-1/2
140
1321141
4
CLAMP
141
1321675
4
CLAMP TOP PLATE
142
8769140
1
CLAMP SET
143
8769123
1
COVER PLATE
144
1001105735
1
DECAL MOUNT PANEL
145
3510832
1
PLATFORM ASSY, (includes items 202 thru 212)
J
146
1001093826
1
DUST CAP
147
1001094555
2
FEMALE QUICK DISCONNECT COUPLING
148
1001094556
2
MALE QUICK DISCONNECT COUPLING
149
1001093827
1
DUST PLUG
152
1001091189
1
HARNESS
154
4812000
4
WASHER, 10mm
155
1001097481
1
HEX HD CAPSCREW, M24X310, GR8.8
157
1001098827
5
HEX LOCKNUT, M24, GR 10
158
1001098828
8
HEX HD CAPSCREW, M12X70, GR10.9
159
1001099751
2
CONNECTOR, 90
160
1001099800
2
HOSE ASSY
161
1001099866
2
LOAD SENSE WIRE CHANNEL
163
4240033
15
WIRE TIE
164
1001098837
Ref
DECALS INSTALLATION, (not shown), (not available to order, see
items 301 thru 312 for service)
F
165
0760807
1
HEX HD CAPSCREW, M8X14, GR8.8
166
1320301
1
CABLE CLAMP
167
3020039
AR
LOCTITE MOLY PASTE
169
4812300
AR
WASHER, 16mm
202
2080040
16
FASTNER
203
2600281
2
HINGE
204
2940074
1
LATCH
206
3510827
1
PLATFORM WELDMENT
207
3520072
1
CAP
208
3820020
4
RIVET
211
4846452
1
GATE WELDMENT
212
3520198
2
PLUG
301
1701518
2
CRUSHING DECAL
302
1701640
1
MANUAL DECAL
303
1702773
3
JLG DECAL
304
1704016
1
FORK LIFT DECAL
305
1704277
3
LANYARD ATTACH GRAPHIC DECAL
307
3820032
4
RIVET
308
8006612
2
STAY CLEAR WARNING DECAL
309
8990147
1
MANUAL HOLDER
310
1001099562
1
CAPACITY WARNING DECAL
311
1001099876
1
OUTRIGGER LOAD DECAL
312
4420051
1.8 m
SAFETY TAPE
