SECTION 2 - BOOM
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 65
FIGURE 2-12. FOURTH BOOM SECTION
ITEM PART NUMBER QTY DESCRIPTION REV
1001133484 1 FOURTH BOOM SECTION ASSEMBLY, (includes all items) A
1 0761010 AR HEX HD CAPSCREW, M10X20, GR8.8, (torque to 50 Nm/37 lb-ft)
2 0761012 AR HEX HD CAPSCREW, M10X25, GR8.8, (torque to 50 Nm/37 lb-ft)
3 0761210 AR HEX HD CAPSCREW, M12X20, GR8.8, (torque to 90 Nm/66 lb-ft)
4 0761212 AR HEX HD CAPSCREW, M12X25, GR8.8, (torque to 90 Nm/66 lb-ft)
5 Ref RETRACT CHAIN COMPONENTS, (See RETRACT CHAINS for
Breakdown)
10 4071085 AR SHIM, 70X200X2mm
11 4071087 AR SHIM, 50X200X4mm
12 4071104 AR SHIM, 70X200X4mm
13 4071105 AR SPACER, 70X200X3mm
14 4071106 AR SPACER, 70X200X4mm
15 4071110 AR SHIM, 50X200X3mm
16 4700032 2 WEAR PAD
17 4740532 AR WASHER, 12mm
18 4812000 AR WASHER, 10mm
19 8002200 4 WEAR PAD
20 8002637 AR SPACER, 70X200X2mm
21 8002904 4 SPACER, 50X200X1mm
22 8003242 2 SPACER, 50X200X1mm
23 1001090150 2 BUSHING
24 1001093784 2 WEAR PAD, (includes grease fittings)
25 1001095650 AR LOCTITE 243
26 1001098457 AR LITHIUM GREASE
27 1001133483 1 WELDMENT
