SECTION 1 - FRAME AND ATTACHING PARTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
15
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
703
1001134286
2
STUD, M10X1-1/2X45, (torque to 55 Nm/41 lb-ft)
704
1001134307
2
WING NUT, M10
705
1784861
2
O-RING
713
0761214
2
HEX SOCKET HD CAPSCREW, M12X30, GR8.8
714
1001101458
2
WING BOLT, M8X40
715
3291201
2
HEX NUT, M12X1-3/4
716
1001095650
AR
LOCTITE 243
717
1001101628
2
BOOM PROP MOUNT BRACKET
802
0760814
8
HEX HD CAPSCREW, (full thread), M8X30, GR8.8, (Germany - if
equipped)
803
806253
2
WEDGE, (Germany - if equipped)
804
806264
2
WEDGE HOLDER, (Germany - if equipped)
805
3290801
8
HEX NUT, M8X1.25, (Germany - if equipped)
808
4811900
16
WASHER, 8mm, (Germany - if equipped)
814
1060628
2
CABLE TIE DOWN, (Germany - if equipped)
1001145746
Ref
COVER PLATE INSTALLATION, (3706PS & 37.6), (not available to
order, see items 901 thru 910 for service)
B
1001168377
Ref
COVER PLATE INSTALLATION, (3706PS & 37.6, if equipped with
trailer options), (not available to order, see items 901 thru 905, 908
& 910 for service)
A
1001145747
Ref
COVER PLATE INSTALLATION, (3707PS, 37.7 & 33.7), (not
available to order, see items 901 thru 910 for service)
B
1001168058
Ref
COVER PLATE INSTALLATION, (3707PS, 37.7 & 33.7, if equipped
with trailer options), (not available to order, see items 901 thru 905,
908 & 910 for service)
A
901
0760812
4
HEX HD CAPSCREW, M8X25, GR8.8, (torque to 28 Nm/20.65 lb-
ft)
902
0761010
8
HEX HD CAPSCREW, M10X20, GR8.8, (torque to 55 Nm/40.56
lb-ft)
903
4811902
4
WASHER, 8mm
904
4812000
8
WASHER, 10mm
905
1001093001BL
2
SIDE HYDRAULIC PANEL, (3706PS, 33.7 & 37.7)
906
1001093007BL
2
SIDE HYDRAULIC PANEL, (3707PS, 33.7 & 37.7)
907
1001093029BL
1
REAR HYDRAULIC PANEL
908
Ref
LOCTITE 243
909
1001095974BL
1
REAR HYDRAULIC PANEL
910
Ref
FRONT HYDRAULIC PANEL, (See BOOM SECTION for
Breakdown)
