SECTION 6 - CAB
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
329
FIGURE 6-4. INTERIOR INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
Ref
AIR CIRCULATION COMPONENTS, (See HEATER
INSTALLATION for Breakdown)
5
7029486
2
SCREW
6
8305919
16
RETAINER NUT, M6X1
8
1001005960
1
HOLDER
9
1001006269
1
LEVEL INDICATOR
10
1001090347
1
HEADLINER COVER
11
1001090348
1
RH POST COVER
12
1001090349
1
LG POST COVER
13
1001139111
1
UPPER FRONT CONSOLE COVER, (EAME)
13
1001139513
1
UPPER FRONT CONSOLE COVER, (NACD)
14
1001139158
1
UPPER SIDE CONSOLE COVER ASSEMBLY, (includes items 201
thru 205)
B
15
1001139160
1
REAR CAB COVER
20
4811900
2
WASHER, 8mm
24
1001098150
20
WASHER, M6
25
1001132564
20
SCREW, M6X20
26
1001102866
1
CAB GROMMET
27
1001111076
2
SPIRE NUT
30
1001094225
1
NET
31
1001100061
4
WASHER
32
1001133260
4
SCREW
101
2080092
1
THUMB SCREW, M6X16mm
102
8305919
26
RETAINER NUT
103
1001097540
17
WASHER, M6
104
1001098150
8
WASHER, M6
105
Ref
AIR CIRCULATION COMPONENTS, (See HEATER
INSTALLATION for Breakdown)
106
1001132564
25
SCREW, M6X20
108
1001121674
1
PARK BRAKE GAITOR COVER
109
1001139230
1
FUSE BOX COVER
110
1001139231
1
RH REAR COVER
111
1001139232
1
SIDE CONSOLE COVER
113
1001139235
1
LOWER FRONT CONSOLE COVER
114
1001139236
1
LH REAR COVER
201
1001143657
1
ARMREST
202
1001097538
2
SCREW, M6X12
203
1001097540
3
WASHER, M6
204
1001104277
1
SCREW, M6X35
205
1001139159
1
UPPER SIDE CONSOLE COVER
