SECTION 2 - BOOM
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
89
FIGURE 2-24. MANITOU MANUAL QUICK ATTACH
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001103157
Ref
MANITOU MANUAL QUICK ATTACH INSTALLATION, (if
equipped), (not available to order, see items 1 thru 13 for service)
B
1
0711234
1
HEX HD CAPSCREW, M12X170, GR10.9, (torque to 115 Nm/85
lb-ft)
2
0761007
1
HEX HD CAPSCREW, M10X14, GR8.8, (torque to 55 Nm/41 lb-ft)
3
2160016
3
GREASE FITTING
4
3291201
1
HEX NUT, M12X1.75
5
4812100
1
WASHER, 12mm
6
1001002523
1
PIN
7
1001008948
1
WASHER
8
0100011
AR
LOCTITE 242
9
1001097141
1
PIN
10
1001098457
AR
LITHIUM GREASE
11
1001103155
1
QUICK ATTACH ASSEMBLY, (includes items 101 thru 103)
A
12
1001098146
AR
SHIM, 72X110X0.5mm
13
1001098147
AR
SHIM, 72X110X1.0mm
101
1001101485
1
WELDMENT
102
1001104349
1
PIN
103
1001104350
1
PIN
