SECTION 5 - DRIVE TRAIN
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
223
FIGURE 5-28. ANCILLARY COMPONENTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
2
70025467
1
FRONT CASE ASSY
20
70025495
4
DOWEL
22
70025468
3
O-RING
23
70025523
4
O-RING
25
70025430
1
REAR CASE ASSY
90
70024646
1
PLUG
203
70025451
4
SOLENOID VALVE
204
70025469
1
RELIEF VALVE
205
70025470
1
RELIEF VALVE
206
70025452
1
PUMP HOUSING
207
70025453
1
HYDRAULIC FILTER ASSY, (R0.784 - 3706PS, 3707PS, 33.7,37.6,
37.7 & 4014PS), (4017PS)
207
70025519
1
HYDRAULIC FILTER ASSY, (R0.861 - 3706PS, 33.7, 3707PS,
37.6, 37.7)
210
70025520
5
CAPSCREW
212
70025458
1
VALVE HOUSING
213
70025521
8
CAPSCREW
214
70025459
1
CHARGE PUMP
216
70025460
1
SUCTION STRAINER
217
70025461
2
O-RING, SUCTION STRAINER
223
70025462
1
DIPSTICK TUBE ASSY
225
70024641
1
CAP
226
70025476
3
CAP
227
70025524
13
PLUG
228
70025526
1
SPEED SENSOR
230
70025527
1
O-RING
232
70025463
4
CAPSCREW
233
70025528
1
SET SCREW
234
70025471
2
PLUG
236
70025522
4
BOLT
237
70025464
1
O-RING
239
70025472
1
WASHER
240
70025473
1
ADAPTER
241
70025465
1
GAGE ASSY
242
70025466
3
O-RING
245
70025474
1
BREATHER
246
70025525
1
O-RING
247
70025475
1
TEMPERATURE SENDER ASSY
250
70025529
1
PLUG
251
70025454
1
VALVE BODY
252
70025455
1
LOCKING NUT ASSY
253
70025456
2
SOLENOID COIL ASSY
254
70025457
2
TUBE ASSY
