JLG 4017PS Parts Manual User Manual
Page 437
SECTION 9 - HYDRAULIC COMPONENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
435
FIGURE 9-7. TILT CYLINDER AND HARDWARE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001125308
1
TILT CYLINDER, (3706PS & 37.6), (includes items 1 thru 18)
C
1001125309
1
TILT CYLINDER, (3707PS, 33.7 & 37.7), (includes items 1 thru 18)
B
1
70020579
1
BARREL, (3706PS & 37.6)
1
70020584
1
BARREL, (3707PS, 33.7 & 37.7)
2
70020580
1
ROD, (3706PS & 37.6)
2
70020585
1
ROD, (3707PS, 33.7 & 37.7)
3
70020581
1
PISTON, (3706PS & 37.6)
3
70020586
1
PISTON, (3707PS, 33.7 & 37.7)
4
70020582
1
GLAND, (3706PS & 37.6)
4
70020587
1
GLAND, (3707PS, 33.7 & 37.7)
5
Kit K1 or K2
1
WIPER SEAL
6
Kit K1 or K2
1
GLAND SEAL
7
Kit K1 or K2
1
O-RING
8
Kit K1 or K2
2
WEAR RING
9
Kit K1 or K2
1
O-RING
10
Kit K1 or K2
1
BACKUP RING
11
Kit K1 or K2
1
O-RING
12
Kit K1 or K2
2
WEAR RING
13
Kit K1 or K2
1
PISTON SEAL
14
Kit K1 or K2
1
O-RING
15
70021499
2
BUSHING
16
70024108
1
LOAD CONTROL VALVE
17
70023087
1
NUT
18
70000699
1
SNAP RING
101
0761007
2
HEX HD CAPSCREW, M10X14, GR8.8, (torque to 55 Nm/40.56 lb-
ft)
103
2160016
2
GREASE FITTING
106
1001008948
2
WASHER
107
1001095650
AR
LOCTITE 243
110
1001097127
1
PIN
111
1001097156
1
PIN
112
1001098457
AR
LITHIUM GREASE LUBE
K1
70020583
1
SEAL KIT, (3706PS & 37.6), (includes items 5 thru 14)
K2
70020588
1
SEAL KIT, (3707PS, 33.7 & 37.7), (includes items 5 thru 14)
