SECTION 5 - DRIVE TRAIN
232
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
31200722
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001142311
2
LHS WHEEL, 14.0-24, (includes items 1, 15 & 16)
A
1001142312
Ref
WHEEL SET, 14.00-24, (Goodyear), (Construction), (4017PS - if
equipped)
B
1001142313
2
RHS WHEEL, 14.0-24, (includes items 1, 15 & 16)
A
1001142314
2
LHS WHEEL, 14.0-24, (includes items 1, 15 & 16)
A
1
1001008719
1
VALVE GROUP
2
1001007846
1
TIRE, 15.5/80-24, 16PLY
3
1001142317
1
WHEEL, (DW14LX24)
4
1001099204
1
TIRE, 400/80-24
5
1001092008
1
TIRE, 460/70-24
6
1001142318
1
WHEEL, (DW15LX24)
7
1001092242
1
TIRE, 15.5/80-24, 14PLY
8
1001003360
1
TIRE, 15.5X25, 12PLY BIAS
9
1001142319
1
WHEEL, (12.00/1.3X25)
10
1001004771
AR
FOAM FILL
11
1001100651
1
TIRE, 440/80-24
12
1001092009
1
TIRE, 500/70-24
13
1001142320
1
WHEEL, (DW14LX24)
14
1001142321
1
WHEEL, (12.00/1.3X24)
15
1001006814
1
TIRE, 14.00-24
16
1001142322
1
WHEEL, (9.00/1.5X24)
17
1001003334
1
TIRE, 14.00-24
