SECTION 10 - ELECTRICAL
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
501
FIGURE 10-7. DRIVING LIGHTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001093179
Ref
DRIVING LIGHT INSTALLATION, (Italy, Germany, France and
ANSI), (not available to order, see items 1 thru 18 for service)
D
1001096953
Ref
DRIVING LIGHT INSTALLATION, (UK, Ireland, CE and Hewden),
(not available to order, see items 1 thru 18 for service)
C
1001115312
Ref
RH DRIVING LIGHT INSTALLATION, (4017PS), (Germany), (not
available to order, see items 1 thru 15, 17 & 18)
A
1001115232
Ref
DRIVING LIGHT INSTALLATION, (4017PS), (UK, Ireland, CE and
Hewden), (not available to order, see items 1 thru 15, 17 & 18)
A
1
0761014
8
HEX HD CAPSCREW, M10X30, GR8.8
2
0761014
4
HEX HD CAPSCREW, M10X30, GR8.8, (4017PS)
2
2920207
1
LH DRIVING LIGHT, (Italy, Germany, France and ANSI)
2
1001002779
1
LH DRIVING LIGHT, (UK, Ireland, CE and Hewden)
2
7029969
1
REPLACEMENT BULB
2
7029970
1
REPLACEMENT BULB, 55W
2
7029971
1
REPLACEMENT BULB, 21W
3
2920208
1
RH DRIVING LIGHT, (Italy, Germany, France and ANSI)
3
1001002778
1
RH DRIVING LIGHT, (UK, Ireland, CE and Hewden)
3
7029969
1
REPLACEMENT BULB
3
7029970
1
REPLACEMENT BULB, 55W
3
7029971
1
REPLACEMENT BULB, 21W
4
3290601
4
HEX NUT, M6X1
5
4811700
4
WASHER, 6mm
6
4812000
8
WASHER, 10mm
6
4812000
4
WASHER,10mm, (4017PS)
7
1001005697
2
TUBE
8
1001005698
2
BRACKET
9
1001005699
4
RUBBER WASHER
10
1001009094
2
HARD WASHER
11
1001009102
2
BOLT, M20X2.5
12
1001091715
1
LH REAR LIGHT
12
70021341
1
REPLACEMENT BULB, 5W
12
70021340
1
REPLACEMENT BULB, 21W
12
7029971
1
REPLACEMENT BULB, 21W
13
1001091716
1
RH REAR LIGHT
13
70021341
1
REPLACEMENT BULB, 5W
13
70021340
1
REPLACEMENT BULB, 21W
13
7029971
1
REPLACEMENT BULB, 21W
14
1001093162
1
BRACKET
15
1001093163
1
BRACKET
16
1001094704
1
BRACKET
17
1001094709
1
BRACKET
18
1001004720
8
STRAP CABLE
