SECTION 8 - HYDRAULIC CIRCUITS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 361
ITEM PART NUMBER QTY DESCRIPTION REV
401 1062255 4 TIE STRAP
402 1001008635 1 HOSE CLAMP
403 1001008466 1 HOSE CLAMP
404 1001008673 3 HOSE CLAMP
406 0761006 3 HEX HD CAPSCREW, M10x12, GR8.8
407 4240127 2 TIE STRAP
408 4812000 3 WASHER, 10mm
409 1001095650 AR LOCTITE 243
410 1001156779 1 HOSE SUPPORT BRACKET
411 1001136549 1 SUCTION HOSE
412 1001136550 1 SUCTION HOSE
413 1001136554 1 HOSE CONNECTOR, 2.5IN
501 Ref STEERING VALVE, (See CONTROLS SECTION for Breakdown)
601 Ref HYDRAULIC TANK ASSY, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
701 Ref FAN PUMP, (See ENGINE AND ATTACHING PARTS SECTION for
Breakdown)
825 1001144779 1 HOSE
826 1001144066 1 NON RETURN VALVE
827 1001142089 2 ADAPTER, CONNECTOR, (includes o-ring)
828 8770143 1 ADAPTER, NUT
829 1001100319 2 CLIP
830 1001008609 2 CLAMP
831 1001125409 1 FITTING, STEM
832 1001144774 1 HOSE
833 1001004723 1 SADDLE
834 471678 2 CABLE BAND
1001146950 1 FAN VALVE INSTALLATION, (non reversing), (3706 & 3707),
(includes items 901 thru 918) C
1001135256 1 FAN VALVE INSTALLATION, (reversing), (33.7, 37.6 & 37.7),
(includes items 901 thru 916) C
901 0700824 2 HEX HD CAPSCREW, M8X80, GR8.8
902 2111010 3 ADAPTER, CONNECTOR, (includes o-ring)
903 2131010 1 ADAPTER, 90, (includes o-ring)
904 2144104 1 TEST PORT
905 2144803 1 ADAPTER, CONNECTOR
906 2171110 1 FITTING, BULKHEAD UNION
907 2172110 1 ADAPTER, 90, (includes o-ring)
908 3290801 2 HEX NUT, M8X1.25
909 4811900 4 WASHER, 8mm
910 1001009163 1 SEAL
911 1001095650 AR LOCTITE 243
912 1001128478 1 TEMPERATURE SENSOR
913 1001132239 1 BULKHEAD SEAL
914 1001132877 1 BAFFLE PLATE, (not shown)
915 1001141800 1 PIPE
916 1001146707 1 COOLING FAN VALVE, (non reversing), (3706 & 3707)
916 1001147289 1 COOLING FAN VALVE, (reversing), (33.7, 37.6 & 37.7)
917 1001155806 1 DUST CAP
918 1001008559 1 CABLE STRAP
1014 1001146260 1 HOSE
1015 1001151913 1 HOSE
