SECTION 3 - ATTACHMENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
103
FIGURE 3-4. FORK POSITIONING CARRIAGE W/FORKS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001091313
1
FORK POSITIONING CARRIAGE W/FORKS, (CE), (includes items
1 thru 35)
A
1
N.S.S.
1
WELDMENT
2
70022922
2
FORKS, (100X50X1200), (2000kg per fork)
3
70021835
2
ROD PIN
4
Ref
NUT, M30X3
5
Ref
WASHER
6
70021836
2
SPLIT PIN
7
70022923
2
CARRIAGE SHAFT
8
70022924
4
SHAFT COLLAR
9
Ref
BOLT, M12X110
10
70021241
4
HEX LOCKNUT, M12
11
70023276
2
CYLINDER
11
70023278
AR
SEAL KIT, (USE WITH CYLINDERS MARKED
1.3351.01C.02.01)
11
70023277
AR
SEAL KIT, (USE WITH CYLINDERS MARKED
1.3351.01C.02.02)
12
Ref
BOLT, M10X70
13
Ref
LOCKNUT, M10
14
70022925
1
ELBOW, 90
15
1001103530
4
BOLT
16
70020730
8
O-RING
17
70021838
1
HOSE ASSY
18
70021839
1
HOSE ASSY
19
70021840
1
HOSE ASSY
20
70021841
1
HOSE ASSY
22
1001103533
3
CLAMP SET, (includes screw and plate)
23
70020731
3
FITTING
24
70022907
6
O-RING
25
70021842
1
COUNTER VALVE
26
70022927
1
O-RING
27
70022928
1
FITTING
28
70022929
1
FITTING
29
70021843
1
PRESSURE VALVE
30
70022906
2
ADAPTER
31
70022930
2
PIPE ASSY
32
1001094555
1
FEMALE QUICK DISCONNECT COUPLING
33
1001094556
1
MALE QUICK DISCONNECT COUPLING
34
Ref
BOLT
35
Ref
HEX NUT, M6
101
1001093826
1
DUST CAP
102
1001093827
1
DUST PLUG
