SECTION 5 - DRIVE TRAIN
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 213
FIGURE 5-24. GEARS AND BEARINGS
ITEM PART NUMBER QTY DESCRIPTION REV
35 70025502 AR SHIM
36 70025501 AR SHIM
37 70025500 AR SHIM
38 70025499 AR SHIM
105 70025400 1 GEAR, 27T
106 70025401 1 GEAR, 45T
107 70025508 2 BEARING CONE
107 70025509 2 BEARING CUP
128 70025402 1 GEAR, 27T
131 70025403 1 GEAR, 36T
132 70025404 1 GEAR, 56T
133 70025405 1 BEARING CUP
133 70025406 1 BEARING CONE
134 70025407 1 BEARING CONE
134 70025408 1 BEARING CUP
137 70025493 1 BEARING CONE
137 70025494 1 BEARING CUP
138 70025409 1 SPACER
149 70025410 AR SPACER, 5.88-5.90
149 70025411 AR SPACER, 5.85-5.87
149 70025412 AR SPACER, 5.82-5.84
149 70025413 AR SPACER, 5.79-5.81
149 70025414 AR SPACER, 6.00-6.02
149 70025415 AR SPACER, 5.97-5.99
149 70025416 AR SPACER, 5.94-5.96
149 70025417 AR SPACER, 5.91-5.93
149 70025418 AR SPACER, 6.09-6.11
149 70025419 AR SPACER, 6.06-6.08
149 70025420 AR SPACER, 6.03-6.05
149 70025421 AR SHIM
149 70025422 AR SHIM
159 70025423 1 GEAR, 24T
160 70025424 4 NEEDLE ROLLER BEARING
161 70025425 1 GEAR, 53T
162 70025401 1 GEAR, 45T
165 70025496 2 BEARING CONE
165 70025497 2 BEARING CUP
167 70025426 1 SPACER
180 70025427 1 OUTPUT SHAFT
181 70025428 1 GEAR, 56T
182 70025407 1 BEARING CONE
182 70025408 1 BEARING CUP
183 70025496 1 BEARING CONE
183 70025497 1 BEARING CUP
231 70025514 35 BOLT
233 70025429 2 WASHER
