SECTION 5 - DRIVE TRAIN
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 225
FIGURE 5-29. FENDER GROUP
ITEM PART NUMBER QTY DESCRIPTION REV
1001116513 Ref FENDER INSTALLATION, (3706PS & 37.6), (not available to order,
see items 1 thru 13 for service) B
1001092767 Ref FENDER INSTALLATION, (3707PS, 33.7, & 37.7), (not available to
order, see items 1 thru 7 & 10 thru 107 for service) D
1001092859 Ref FENDER INSTALLATION, (4014PS), (not available to order, see
items 1 thru 13 for service) D
1001092860 Ref FENDER INSTALLATION, (4017PS), (not available to order, see
items 1 thru 7 & 10thru 107 for service) E
1 0700612 16 HEX HD CAPSCREW, M6X25, GR8.8, (torque to 8 Nm/6lb-ft)
2 0760812 16 HEX HD CAPSCREW, M8X25, GR8.8, (torque to 8 Nm/6 lb-ft)
3 0761615 16 HEX HD CAPSCREW, M16X25, GR8.8
4 3290605 16 HEX LOCKNUT, M6X1, GR8
5 4811702 32 WASHER, 6 MM
6 4811902 32 WASHER, 8 MM
7 4812300 16 WASHER, 16 MM
8 1001140245 1 LH REAR FENDER BRACKET, (3706PS & 37.6)
9 1001140246 1 RH REAR FENDER BRACKET, (3706PS & 37.6)
10 1001095650 AR LOCTITE 243
11 1001100845 3 FENDER, (3706PS, 37.6 & 4017PS)
11 1001100845 4 FENDER, (3707PS, 33.7, 37.7 & 4014PS)
12 1001140247 2 FRONT FENDER BRACKET, (3706PS & 37.6)
13 1001116543 1 CUT-OUT FENDER, (3706PS & 37.6)
13 1001117995 1 CUT-OUT FENDER, (4017PS)
106 1001139858 2 LH FENDER BRACKET, (3707PS, 33.7 & 37.7)
106 1001141156 2 LH FENDER BRACKET, (4014PS)
106 1001140687 2 LH FENDER BRACKET, (4017PS)
107 1001139859 2 RH FENDER BRACKET, (3707PS, 33.7 & 37.7)
107 1001141157 2 RH FENDER BRACKET, (4014PS)
107 1001140688 2 RH FENDER BRACKET, (4017PS)
