SECTION 2 - BOOM
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
75
FIGURE 2-17. MANUAL QUICK ATTACH
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001131347
Ref
MANUAL QUICK ATTACH INSTALLATION, (if equipped), (not
available to order, see items 2 thru 18 for service)
E
2
0760605
1
HEX HD CAPSCREW, M6X10, GR8.8, (torque to 12 Nm/9 lb-ft)
3
0761007
2
HEX HD CAPSCREW, M10X14, GR8.8, (torque to 55 Nm/40.5 lb-
ft)
4
0761010
5
HEX HD CAPSCREW, M10X20,GR8.8, (torque to 55 Nm/40.5 lb-
ft)
5
1001161673
1
CHAIN
6
2160016
5
GREASE FITTING
8
4812000
5
WASHER, 10mm
9
8002027
1
ROD
10
1001008948
2
WASHER
11
1001154471
1
WELDMENT
12
1001154968
1
COVER
13
1001132895
1
PIN
14
1001132898
1
PIN
15
1001098457
AR
LITHIUM GREASE
16
1001095650
AR
LOCTITE 243
17
1001098146
AR
SHIM, 72X110X0.5mm
18
1001098147
AR
SHIM, 72X110X1.0mm
