SECTION 8 - HYDRAULIC CIRCUITS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
375
FIGURE 8-5. STEER SELECT CIRCUIT
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
2110608
5
ADAPTER, CONNECTOR, (includes o-ring)
7
4031913
2
SOCKET HD CAPSCREW, M8X45, GR8.8, (torque to 28 Nm/20.65
lb-ft)
8
Ref
STEERING SELECT VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
10
1001144846
1
HOSE ASSY
11
1001144838
2
HOSE ASSY, (3706PS & 37.6)
11
1001144849
2
HOSE ASSY, (3707PS, 33.7 & 37.7)
12
1001144845
1
HOSE ASSY
13
1001144847
1
HOSE ASSY
18
Ref
GROMMET, (See DUMP CIRCUIT for Breakdown)
30
1001094262
4
ADAPTER, 90, (includes o-ring)
38
1302325
4
DISK
39
2997586
2
CLIP BODY
40
4010614
4
PAN HD SCREW, M6X30
41
1001095650
AR
LOCTITE 243
42
2150608
1
ADAPTER, 45, (includes o-ring)
102
Ref
ORBITAL STEERING VALVE, (See CONTROLS SECTION for
Breakdown)
