SECTION 7 - CONTROLS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
347
FIGURE 7-1. BRAKE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001002993
Ref
BRAKE INSTALLATION, (not available to order, see items 1 thru 4
for service)
B
1
4360658
1
BRAKE LIGHT SWITCH
2
7029486
2
SCREW
3
0100011
AR
LOCTITE 242
4
1001097345
Ref
BRAKE PEDAL INSTALLATION, (not available to order, see items
101 thru 119 for service)
D
101
0701015
1
HEX HD CAPSCREW, 10X35mm, GR8.8
102
3290801
2
HEX NUT, 8X1.25mm
103
3291001
1
HEX NUT, 10X1.5mm
104
4811900
2
FLAT WASHER, 8mm
105
1001003000
2
SNAP RING
106
1001003797
1
GASKET
107
1001116431
1
LEVER ASSY
108
1001116423
2
PLATE
109
1001007591
1
SPRING
110
1001008730
3
BUSHING
111
1001009104
4
HARD WASHER
112
1001009133
1
ROD
113
1001009219
3
PIN
114
1001009220
3
CLIP
115
1001117360
1
MASTER BRAKE CYLINDER
118
1001007417
1
BRAKE PEDAL
119
1001104280
1
HEX NUT, 10X1.5mm, GR8
