SECTION 9 - HYDRAULIC COMPONENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
461
FIGURE 9-18. PISTON PUMP
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001121053
1
HYDRAULIC PISTON PUMP, 63cc, (3706PS, 3707PS, 4017PS,
33.7, 37.6 & 37.7), (includes items 1 thru 310)
B
1001121054
1
HYDRAULIC PISTON PUMP, 45cc, (4014PS), (includes items 1
thru 310)
A
1
70003738
1
CONTROL VALVE
2
70024186
1
CONTROL VALVE
3
70024187
1
ADJUSTING PIECE
30
70024407
2
PLUG
40
70024408
1
STOP SCREW
43
70024409
1
O-RING
101
70024411
1
ROTARY GROUP
107
70024412
1
SWASH PLATE
108
70024413
1
DRIVE SHAFT
115
7024943
1
BEARING
116
7024944
1
BEARING
117
70024414
1
BEARING-LINER
118
70024415
1
BEARING-LINER
119
7024953
2
SCREW
120
80634004
1
SHAFT SEAL
121
7024948
1
O-RING
124
7024950
2
SEAL RING
125
80334277
1
RETAINING RING
202
70021867
1
GASKET
203
7024954
4
SOCKET HD CAPSCREW
204
70024416
1
PLUG
307
91084318
1
SOLENOID
309
7024949
1
O-RING
310
70024417
3
R-RING
K1
70024410
1
SEAL KIT, (includes items 30, 43, 120 thru 125, 202, 204, 309 &
310)
