SECTION 1 - FRAME AND ATTACHING PARTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
27
FIGURE 1-5. RETRIEVAL HITCH
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001098458
1
RETRIEVAL HITCH, (3706PS, 3707PS, 33.7, 37.6 & 37.7), (if
equipped), (includes all items)
C
1001005207
1
RETRIEVAL HITCH, (4014PS & 4017PS), (if equipped), (includes
all items)
C
1
0711624
2
HEX HD CAPSCREW, M16X80, GR10.9, (3706PS, 3707PS, 33.7,
37.6 & 37.7)
1
1001151044
2
HEX HD CAPSCREW, M20X75, GR12.9, (4014PS & 4017PS)
2
1001003803
1
RING PIN
3
1001005267
1
PIN
4
5241600
4
WASHER, 16mm, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
4
1001009094
4
HARD WASHER, (4014PS & 4017PS)
5
3331611
2
HEX NUT, M16X2, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
5
1001009095
2
FULL NUT, (4014PS & 4017PS)
6
1001106570
1
RETRIEVAL HITCH, (3706PS, 3707PS, 33.7, 37.6 & 37.7)
6
1001005134
1
RETRIEVAL HITCH, (4014PS & 4017PS)
7
1001095650
AR
LOCTITE 24
