SECTION 8 - HYDRAULIC CIRCUITS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 397
FIGURE 8-16. TILT AND TILT COMPENSATION CYLINDER CIRCUIT
ITEM PART NUMBER QTY DESCRIPTION REV
3 0700614 2 HEX HD CAPSCREW, 6X30mm, GR8.8, (torque to 12 Nm/8.8 lb-ft)
4 0700617 4 HEX HD CAPSCREW, 6X40mm, GR8.8, (torque to 12 Nm/8.8 lb-ft)
19 1001008805 2 SEAL
20 1001009124 6 HARD WASHER
22 1001092129 2 CLAMP WITH COVER
24 1001093387 4 CLAMP HALF
25 1001144561 2 HOSE ASSY
26 1001097391 1 HOSE CARRIER
27 1001097902 1 PIPE ASSY
28 1001097903 1 PIPE ASSY
32 1001103554 2 CLAMP COVER PLATE
105 0760818 2 HEX HD CAPSCREW, 8X50mm, GR8.8
107 0761010 2 HEX HD CAPSCREW, 10X20mm, GR8.8, (torque to 55 Nm/40.5 lb-
ft)
110 2110604 2 ADAPTER, (includes o-ring)
112 2110812 2 ADAPTER, (includes o-ring)
119 2170508 2 TEE FITTING, (includes o-ring)
120 2170808 2 TEE FITTING, (includes o-ring)
130 1001002496 2 PIN
134 1001005961 2 CLIP
139 1001026104 4 CLIP
144 1001094705 4 HOSE ASSY
148 1001144871 1 HOSE ASSY
149 1001144872 1 HOSE ASSY
153 1001097289 1 PIPE ASSY
154 1001097290 1 PIPE ASSY
157 1001098128 2 CLAMP
166 Ref TILT COMPENSATION CYLINDER, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
164 Ref MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
209 Ref TILT CYLINDER, (See HYDRAULIC COMPONENTS SECTION for
Breakdown)
202 2110808 2 CONNECTOR, (includes o-ring)
204 2172108 2 ELBOW, 90, (includes o-ring)
304 3290601 8 HEX NUT, 6X1mm, (torque adjusting nut to 3 Nm/2.2 lb-ft), (torque
locking nut to 12 Nm/8.8 lb-ft)
310 1001103495 2 CHAIN ANCHOR BRACKET
319 1001113286 1 CLAMP
