SECTION 9 - HYDRAULIC COMPONENTS
31200722
4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS
429
FIGURE 9-4. EXTEND/RETRACT CYLINDER AND HARDWARE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001114783
1
EXTEND/RETRACT CYLINDER, (3706PS & 37.6), (includes items
1 thru 21)
B
1001114784
1
EXTEND/RETRACT CYLINDER, (3707PS, 33.7 & 37.7), (includes
items 1 thru 21)
B
1
70023911
1
BARREL, (3706PS & 37.6)
1
70023922
1
BARREL, (3707PS, 33.7 & 37.7)
2
70023912
1
ROD, (3706PS & 37.6)
2
70023923
1
ROD, (3707PS, 33.7 & 37.7)
3
70023913
1
GLAND
4
70023914
1
PISTON
5
70023915
1
SET SCREW, M6X8
6
70023916
4
SCREW, M8X45
7
1001002815
1
LOAD CONTROL VALVE
8
70023918
2
BUFFER DISC
9
70023919
4
SCREW, M8X25
10
70023920
1
SPACER
11
Kit K1
2
BEARING
12
Kit K1
1
PISTON SEAL
13
Kit K1
2
BACKUP RING
14
Kit K1
1
O-RING
15
Kit K1
2
ROD BEARING
16
Kit K1
1
O-RING
17
Kit K1
1
BACKUP RING
18
Kit K1
1
ROD SEAL
19
Kit K1
1
O-RING
20
Kit K1
1
WIPER SEAL
21
Kit K1
1
O-RING
101
314689
4
CIRCLIP
110
8307904
AR
SHIM
111
8310093
AR
SHIM
112
1001002489
1
PIN
113
1001002498
1
PIN
123
1001092297
2
SPACER
K1
70023921
1
SEAL KIT, (includes items 11 thru 21)
