SECTION 8 - HYDRAULIC CIRCUITS
31200722 4014PS,4017PS,33.7,37.6,37.7,3707PS,3706PS 407
FIGURE 8-19. AUXILIARY HYDRAULIC CIRCUIT
ITEM PART NUMBER QTY DESCRIPTION REV
3 0700614 2 HEX HD CAPSCREW, 6X30mm, GR8.8, (torque to 12Nm/8.8lb-ft)
4 0700617 6 HEX HD CAPSCREW, 6X45mm, GR8.8, (torque to 12Nm/8.8lb-ft)
6 2171208 2 ELBOW, 90, (includes o-ring)
7 2172208 2 BULKHEAD NUT
9 3290601 2 HEX NUT, 6X1mm
12 4812000 2 FLAT WASHER, 10mm
18 1001144560 1 HOSE ASSY
20 1001009124 12 HARD WASHER
21 1001009326 2 TORX HD CAPSCREW, 10X20mm
22 1001092129 2 CLAMP SET
24 1001093387 4 CLAMP HALF
29 1001097904 1 PIPE ASSY
30 1001097905 1 PIPE ASSY
31 1001098386 1 BULKHEAD PLATE
32 1001103554 2 CLAMP COVER PLATE
37 1001104821 1 HOSE CLAMP PLATE
112 2110812 2 ADAPTER, (includes o-ring)
137 1001008805 2 SEAL
146 1001144869 1 HOSE ASSY
147 1001144870 1 HOSE ASSY
157 Ref CLAMP, (See TILT AND TILT COMPENSATION CYLINDER
CIRCUIT for Breakdown)
164 Ref MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
241 Ref THIRD BOOM SECTION, (See BOOM SECTION for Breakdown)
313 1001119560 1 PLATE, BOX SECTION
1001146389 Ref VALVE GROUP INSTALLATION, (not available to order, see items
401 thru 411 for service) A
401 1001003400 2 FITTING, CONNECTOR
402 1001003411 2 FITTING, CONNECTOR
403 1001101042 1 QUICK DISCONNECT COUPLING, FEMALE
404 1001101041 1 QUICK DISCONNECT COUPLING, MALE
405 1001005262 2 HARD WASHER
406 1001005904 2 ELBOW, 45
407 Ref DIVERTER VALVE, (See HYDRAULIC COMPONENTS SECTION
for Breakdown)
408 4031918 2 SOCKET HD CAPSCREW, M8X70, (torque to 12-14 Nm/8.85-
10.32 lb-ft)
409 1001108918 1 PLATE
410 1001004720 2 CABLE STRAP
411 Ref HYDRAULIC LOCK SWITCH, (See ELECTRICAL SECTION for
Breakdown)
524 Ref HOSE ASSY, (See BOOM SECTION for Breakdown)
