SECTION 7 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
7-14 – JLG Lift – 3121166
32 CAN Bus Low Input/Output Comm
33 CAN Bus Shield Output 0
34 CAN Bus High Input/Output Comm
35 CAN Bus Low Input/Output Comm
36 CAN Bus Shield Output 0
37 Ground Power Output 0
38 Ground Enable Power Output 0
39 Master Ignition Connection Power Input Vbatt
40 Master Ground Connection Power Input 0
Table 7-2. Ground Board J2
Pin Function Type Range (V)
1 Ignition Power Output Vbatt
2 Ground EMS Power Input Vbatt
3 Platform EMS Source Power Input Vbatt
4 Ground Mode Select Input Vbatt
5 Ground Power Output 0
6 Ground Lift Up Input Vbatt
7 Ground Lift Down Input Vbatt
8 Hour Meter Output Vbatt
9 Ground Overload Lamp Output Vbatt
Table 7-3. Ground Board J3
Pin Function Type Range (V)
1 Tilt Sensor Power Power Output 12
2 Tilt Sensor X-Axis (PWM) Input 12
3 Tilt Sensor Y-Axis (PWM) Input 12
4 Ground Power Output 0
Table 7-1. Ground Board J1 (1600346 Power Module ONLY)
Pin Function Type Range (V)
