SECTION 1 - SPECIFICATIONS
3121166
– JLG Lift –
1-3
Tires
Batteries
NOTICE
JLG MACHINES EQUIPPED WITH DELTA Q BATTERY CHARGERS
ARE DESIGNED FOR THE BEST PERFORMANCE WITH OEM FAC-
TORY APPROVED BATTERIES.
APPROVED JLG REPLACEMENT BATTERIES ARE AVAILABLE
THROUGH JLG'S AFTERMARKET PARTS DISTRIBUTION CENTERS
OR JLG'S AFTERMARKET PROGRAMS. FOR ASSISTANCE WITH
PROPER BATTERY REPLACEMENT, PLEASE CONTACT YOUR
LOCAL JLG SUPPORT OFFICE.
BATTERIES APPROVED BY JLG HAVE BEEN TESTED FOR COMPAT-
IBILITY WITH THE ALGORITHM PROGRAMMING OF THE DELTA
Q B AT TE R Y C H A R G E R TO O P T I M I Z E B AT T E R Y L I FE A N D
MACHINE CYCLE TIMES. THE USE OF NON APPROVED BATTER-
IES IN YOUR JLG EQUIPMENT MAY RESULT IN PERFORMANCE
ISSUES OR BATTERY CHARGER FAULT CODES. JLG ASSUMES NO
RESPONSIBILITY FOR SERVICE OR PERFORMANCE ISSUES ARIS-
ING FROM THE USE OF NON APPROVED BATTERIES.
Motors
Drive Motor
Type: Shunt Wound, Sepex 24V DC
Power: 0.65 Horsepower @ 3750 rpm
Hydraulic Pump/Electric Motor Assembly
(All Models)
Type: Series Wound Permanent Magnet 24V DC
Power: 3kW
Battery Charger
20 Amp SCR
110/250 Volts AC - 50/60 Hz input
24 Volts DC - 20 Amp output w/auto timer
Japanese Specification
100/200 Volts AC - 50/60 Hz input
24 Volts DC - 20 Amp output w/auto timer
Table 1-4. Tire Specifications
Description
1930ES
2030ES
2630ES
2646ES
3246ES
Size
323mm x 100mm
406 mm x 125 mm
Max Tire Load
2500 lbs (1134 kg)
4000 lbs (1814 kg)
Wheel Bolt Torque
105 - 120 ft lb (142-163 Nm)
