SECTION 1 - SPECIFICATIONS
3121166 – JLG Lift – 1-7
1.4 LIMIT SWITCHES
Tilt Alarm
Illuminates a light on the platform, sounds an alarm and
cuts out lift up and drive when the machine is out of
level and above stowed depending on model and speci-
fications.
High Drive Speed Cutout
High drive speed is cut out when the platform is raised
above the preset height per model as follows:
NOTE: These figures are given with a tolerance of ± 6 in
(0.15 m).
Pressure Settings
Table 1-12. Tilt Settings
Model
Tilt Setting
(front to back)
Tilt Setting
(side to side)
Maximum Deck
Elevation
1930ES 3°
1.5°
2°
2.5°
3°
18.75 ft (5.7 m)
14 ft (4.3 m)
11 ft (3.4 m)
9 ft (2.7 m)
2030ES 3°
1.5°
2°
2.5°
3°
20 ft (6 m)
15 ft (4.5 m)
12 ft (3.7 m)
10 ft (3 m)
2630ES 3°
1.5°
2°
2.5°
3°
25.4 ft (7.7 m)
20 ft (6 m)
16 ft (4.9 m)
13 ft (4 m)
2646ES 3°
2°
2.5°
3°
26 ft (7.9 m)
22 ft (6.7 m)
20 ft (6 m)
3246ES 3°
2°
2.5°
3°
31.75 ft (9.7 m)
22 ft (6.7 m)
20 ft (6 m)
Table 1-13. High Drive Speed Cutout Height
Model High Drive Speed Cutout
1930ES 54 in (1.4 m)
2030ES 66 in (1.7 m)
2630ES 76 in (1.9 m)
2646ES 76 in (1.9 m)
3246ES 76 in (1.9 m)
Table 1-14. Pressure Settings
Model Lift Relief Steer Relief
1930ES
1800 psi ± 50 psi
(124 bar ± 3.4 bar)
1500 psi
(103 bar)
2030ES
1800 psi ± 50 psi
(124 bar ± 3.4 bar)
1500 psi
(103 bar)
2630ES
1950 psi +/- 50 psi
(134 bar ± 3.4 bar)
1500 psi
(103 bar)
2646ES
2000 psi +/- 50 psi
(138 bar ± 3.4 bar)
1500 psi
(103 bar)
3246ES
2000 psi +/- 50 psi
(138 bar ± 3.4 bar)
1500 psi
(103 bar)
