RADWAG BALANCES 3Y SERIES - Manual (Page 70)

- 70 -
Print data from header
Print data from footer
Caution:
Measuring units for printing mass indication:
− Net – main measuring unit (adjustment unit)
− Tare – main measuring unit (adjustment unit)
− Gross – main measuring unit (adjustment unit)
− Current result – currently displayed measuring unit
− Supplementary unit – supplementary measuring unit
− Mass – main measuring unit (adjustment unit)
Non-standard printout

Non-standard printout
a printout may contain: TEXTS and VARIABLES(which are acquired from
the software on printout).
Each non-standard printout is a separate project, featuring specific name,
by which it is identified, and saved in the database of printouts.
PROCEDURE:
1. Press option
2. Press key
3. A window is opened with data such as Name/Code/Project
4. Set name and code of a printout
5. Press key
6. A keyboard is opened on the display for editing the printout
7. Use keyboard to design printout template, the printout may contain
texts and variables.
Caution:

User can add a printout by importing configured texts from data storage devices
connected to balance’s USB port.

Printout’s name is ONLY a NAME, and it is not part of its content.

Means of designing a non-standard printout template is described in point 24.11
of this user manual
15.6. Profiles
Profiles are described in point 14, Profiles, of this user manual.
