24. PIPETTE CALIBRATION
Balance allows pipette calibration by means of a special balance software or by
means of cooperation with computer software “Pipettes” intended for pipettes calibration
(workstation for pipettes calibration).
Before pipettes calibration a special set must be mounted inside the draft shield. The
set is an atypical balance equipment. See the picture below for set assembly instruction.
MYA 3Y balance with a set for pipettes calibration
Calibration set assembly procedure:
•
dismantle the weighing pan and the draft shield
• inside the chamber place:
• pan shield (1),
• bottom ring (2),
• balance pan (3),
• glass vessel (5),
• evaporation ring (6),
• glass shield (7),
• supplementary shield (8),
• or glass shield (4),
XA 3Y balance with a set for pipettes calibration:
Calibration set assembly procedure:
•
dismantle the weighing pan and the draft shield,
• place centering ring (8) inside the chamber,
• put glass ring (7) onto the centering ring,
• place weighing pan (6) inside the glass ring,
• put top ring (5) onto the glass ring,
• put evaporation ring (4) onto the top ring (5)
• insert calibration vessel (3) into the evaporation ring,
• put the glass cover (2) onto the top ring,
• put glass supplementary cover (1) onto the glass cover.
