Additional display – RADWAG BALANCES 3Y SERIES User Manual
Page 196
- 196 -
Caution:
For correct balance’s cooperation with a transponder card reader set appropriate baud
rate value in submenu <
Communication> (default 9600b/s).
Transponder card scanner port.
The balance enables communicating with a transponder card scanner using
the following ports:
•
RS 232 (COM1),
•
RS 232 (COM2).
Assigning number of a card to a user:
In order to log in an operator using a transponder card scanner, first assign a
number of an already registered card to a selected user in the database of
operators.
Procedure:
•
Connect a transponder card scanner to a balance’s port (RS 232 COM1 or
RS 232 COM2), select communication port in balance settings for the
transponder card scanner
•
In submenu <
Communication> set baud rate for compatible with the
one of the transponder card scanner (default 9600b/s).
•
Enter the database of operators and edit desired operator’s record, go to <
Card number> option,
•
On entering editing mode in <
Card number> option, an editing window
•
Approximate the card to the transponder card scanner. The balance
automatically displays number of detected card in the
field,
•
Accept recognized number by pressing
key and returning to the main
window of weighing mode.
31.5. Additional display
The balance enables communicating with an additional display using the
following ports:
•
RS 232 (COM1),
•
RS 232 (COM2),
•
Tcp.
Type of data displayed on an additional display is declared in variable (template)>. Procedure – designing a variable − Enter group of parameters < Peripheral devices> − Press “ Additional display / Project” field, which opens an editing window
