16 Communication Protocols
16.1 Protocol 3000
The VS-1616D can be operated using serial commands from a PC, remote
controller or touch screen using the Kramer Protocol 3000.
This section describes the:
• Kramer Protocol 3000 syntax (see Section 16.1.1
• Kramer Protocol 3000 commands (see
)
Section 16.1.8
16.1.1 Kramer Protocol 3000 Syntax
)
16.1.1.1 Host Message Format
Start Address (optional) Body Delimiter
# device_id @ Message CR
16.1.1.2 Simple Command
Command string with only one command without addressing:
Start Body Delimiter
# Command SP Parameter_1,Parameter_2,… CR
16.1.1.3 Command String
Formal syntax with commands concatenation and addressing:
Start Address Body Delimiter
# device_id @ Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3 Parameter3_1,Parameter3_2,…|…
CR
16.1.2 Device Message Format
Start Address (optional) Body delimiter
~ device_id @ Message CR LF
